1. A “2-in-1” Solution for Video Surveillance & Industrial Data Collection
In modern industrial systems, collecting data from external devices such as sensors, PLCs, and power meters through the Modbus RTU (RS485) protocol is very common. However, integrating these devices with video surveillance systems still faces many limitations.
By combining AI cameras powered by the RV1106 chipset with RS485 communication, this solution provides a comprehensive platform that enables both video monitoring and industrial data collection in a single system.
2. System Architecture
The system includes:
Bullet IP Camera (Video recording, AI processing, and data processing)
Modbus RTU Devices (Sensors, PLCs, power meters, industrial devices, etc.)
RS485 Converter Device
Server or Central Monitoring System
3. Key Advantages
2-in-1 Integration: No separate Modbus gateway is required, helping reduce hardware costs and simplify deployment.
Edge Data Processing on Camera: Data is processed directly on the camera, reducing latency and improving overall system stability.
Flexible Expansion: Supports a wide range of Modbus-compatible devices including sensors, PLCs, and industrial controllers.
Easy Integration: Can be integrated into IoT platforms, SCADA systems, and existing industrial management solutions.
Real-Time Visual Monitoring: Monitor environmental and operational data such as temperature, voltage, and device status directly alongside live video feeds.
4. Real-World Applications
a, CNC Machine & Production Line Monitoring
Industrial machines and CNC systems often provide Modbus data such as status, speed, and error information, but lack visual verification.
Solution
Combine industrial data with real-time video monitoring.
Verify whether machines are operating or stopped through live images.
Monitor machine areas directly.
Reduce downtime and improve operational efficiency.
b, Electrical Cabinet Monitoring & Fault Detection
Electrical cabinets may provide voltage, current, and temperature readings, but data alone is often insufficient to identify the actual cause of issues.
Solution
Cameras collect electrical data through RS485 communication.
Real-time images can be viewed immediately when alerts occur.
Detect sparks, fire, or incorrect operations.
Store complete logs including both data and video footage.
c,Smart Agriculture
Environmental sensors can provide temperature and humidity data, but they cannot visually show the condition of crops.
Solution
Cameras collect sensor data while recording live images of crops.
Detect diseases, wilting, or abnormal conditions early.
Improve irrigation and crop management efficiency.
Combine environmental data with visual monitoring in one system.
d, Hazardous Area Monitoring
(Chemical Plants, Restricted Areas, High-Risk Zones)
Monitoring dangerous or restricted environments with high chemical concentrations can be extremely challenging, especially when temperature or pressure levels increase unexpectedly.
Solution
Use cameras to monitor environmental data and restricted zones.
Trigger alerts when people enter dangerous areas.
Detect leaks and abnormal conditions early.
Reduce human exposure to hazardous environments.
